A
MODULE SPECIFICATIONS
Network interface
ConnectCore
Wi-9C
?
?
?
?
Operating temperature: -30° C to +75° C (-22° F to +167° F)
Storage temperature: -40° C to +125° C (-40° F to 257° F)
Relative humidity: 5% to 95% (non-condensing)
Altitude: 12,000 ft (3657.6 m)
..................................................................................
Network interface
Ethernet
WLAN
?
?
?
?
?
?
?
Standard: IEEE 802.3
Physical layer: 10/100Base-T
Data rate: 10/100 Mbps (auto-sensing)
Mode: Full or half duplex (auto-sensing)
On-board connector: RJ-45 with magnetics (optional)
802.3af power pass-through (mid-span and end-span)
Standard: IEEE802.11b/g
Frequency: 2.4 GHz
–
Data rate: Up to 54 Mbps with fallback
–
Modulation: DBPSK (1 Mbps), DQPSK (2 Mbps), CCK (11,5.5 Mbps), BPSK (6,9
–
Mbps), QPSK (12,18 Mbps), 16-QAM (24,36 Mbps), 64-QAM (48,54 Mbps)
Transmit power: 16 dBm typical
–
Receive sensitivity:
–
Data Rate
11Mbps
54Mbps
MIN
-76 dBm
-65 dBm
TYP
-87 dBm
-73 dBm
?
Connector: 1/2 x RP-SMA or 2 x U.FL
..................................................................................
Power requirements
ConnectCore 9C
ConnectCore
Wi-9C
?
?
?
Module: 3.3VDC @ 0.75A max
USB interface: 5VDC @ 0.5A max per port (optional)
Module: 3.3V ± 5% @ 0.95A max, 0.70A typ
66
ConnectCore 9C/Wi -9C Hardware Reference, Rev D 05/2010
